Black PE Jacket Outdoor Optical Fiber Cable GYTC8S / Self Supporting Cable
There are indoor cable and outdoor cable, single mode and multimode cable, simplex, duplex or multi-core cable.
Innovative loose tube cable fulfill the need for every situation, and provide excellent performance. Our complete portfolio offers cables with increased fiber density and easy deployment for a wide range of installations, including duct, aerial (lashed and self-supporting), direct buried, and outdoor/indoor.
Armored Fiber Optic Cable is used by the military, industrial applications as in petrochemical, industrial plants including nuclear and utilities are installed by direct burial in areas where rodents are a problem. The armored fiber cable construction provides additional crush and rodent protection, and this means the armored cable is conductive, so it must be grounded properly.
FOC Communication Co., ltd manufactures Loose Tube Armored Cable, Ribbon Armored Cable, Tight-Buffered Armored Cable, Distribution Armored Cable, Breakout Armored Cable, Self-Supporting Armored Cable, etc. to meet customers’ different requirements. All of armored fiber optic cable price is flexible depending on the quantities of your order.we also supply & OEM other indoor/outdoor/FTTH used fiber optical cables.
Features
Loose tube style ,figure-8 optical fiber cable
Jelly compound, protect the cladding fiber
Filling compound and water-proof tape Amoured with corrugated steel tape
Incorporation steel messenger wire suitable for overhead installation as pole to pole or pole to premises.
High strength, tracking-resistant sheath
Application
Usable for aerial installation
Long-haul communication systems
Junction communication systems
Subscriber network systems
Local area network systems
Specifications
|
Fiber Count
|
6,12,24
|
36
|
48,60
|
72
|
144
|
|
Max.cores in tube
|
6
|
6
|
12
|
12
|
12
|
|
Element no.
|
5
|
6
|
5
|
6
|
12
|
|
O.D.(mm)
|
9.8
|
10.3
|
10.8
|
11.4
|
16.5
|
|
Approx.weight
|
200
|
210
|
220
|
240
|
280
|
|
Max.Tensile strength(N)
|
According to the demand of design, 5KN---10KN
|
|
Max.Crush Resistance
|
Long term
|
300
|
|
Short term
|
1000
|
|
Min.Bending Radius
|
Dynamic
|
≥20D cable diameter
|
|
Static
|
≥10D cable diameter
|
